Key Features
- Specialized for essential oils
- Natural oil extraction
- Borosilicate glass construction
- High purity distillation
BOOK FREE HOME COLLECTION
Essential Oil Distillers
Essential Oil Distillers
Essential Oil Distillers
Specialized essential oil distillers for natural oil extraction and purification.
Essential Oil Distillers Overview
The Essential Oil Distillers are specialized glass units designed to extract volatile aromatic compounds from botanical materials via steam or vacuum distillation. Offered in capacities such as 10 L, 20 L, 50 L, 100 L, and 200 L, these systems maintain high purity and efficiency by separating volatile oils while leaving behind non-volatile residues. In steam mode, water is boiled in a separate vessel, and steam passes through the plant mass, carrying volatile vapors to the condenser. In vacuum mode, reduced pressure lowers boiling points, preserving thermally sensitive compounds. The modular design supports easy integration of condensers, receivers, and feed systems.
Specifications
• Available units: EOSD 10 (10 L), EOSD 20 (20 L), EOSD 50, EOSD 100, EOSD 200
• Mantle heating power: e.g. 1 kW for 10 L, 1.8 kW for 20 L, 3.6 kW for 50 L, 5.4 kW for 100 L, 8.1 kW for 200 L
• Addition/feed vessel: e.g. 5 L for smaller units, 20 L or 50 L for larger units
• Condenser heat transfer area: e.g. 0.35 m² for 10 L, up to 2.25 m² for 200 L
• Receiver size matched to reactor (e.g. 5 L to 50 L)
• Operating modes: atmospheric steam distillation or full vacuum distillation
• Wetted materials: borosilicate glass, PTFE seals, corrosion-resistant supports
• Modular connectivity for condensers, reflux lines, and vacuum systems
Applications
• Extraction of essential oils and fragrances from flowers, herbs, and seeds
• Small-batch production of natural aromas and flavors
• Research and development in natural product chemistry
• Quality assurance for botanical extracts
• Educational demonstration of steam and vacuum distillation
These distillers are particularly suited when preservation of delicate aroma compounds is critical, and when flexibility between steam and vacuum modes is needed.
